Page 19
Reset Factory Default Settings
Note: Resetting Factory Default Settings erases all of the values entered by
the user. Record any necessary settings before proceeding.
Warning: Erasing the user entered values may result in a safety hazard and
system malfunction.
The following instructions will reset the controller to the original factory
default settings.
Step 1. Press the INDEX KEY while at the Home Display until the
controller reads LoC in the process display. Use the UP
arrow to select LoC1. Press the ENTER KEY to save this
value.
Step 2. Press and hold the UP and DOWN arrows
simultaneously for one second. Upon releasing the
buttons, the display will read SHou in the PV display
and oFF in the SV display.
Step 3. Press the INDEX key once and the controller will read
PASS in the PV display and a 4321 in the SV display.
Adjust the value in the SV display to 1357 using the UP
nd DOWN arrows. Press the ENTER KEY to save the value.
Step 4. Cycle the power on the controller. Upon power up, all of the
user set values have been erased.
Page 20
SPECIFICATIONS
Input Voltage
Operation Voltage Range
Power Consumption
Memory Protection
Display Method
Sensor Type
Control Mode
Control Output
Display Accuracy
Sampling Range
RS-485 Communication
Vibration Resistance
Shock Resistance
Ambient Temperature
Storage Temperature
Altitude
Relative Humidity
100 to 240VAC 50/60Hz.
85% to 110% of rated voltage.
5VA max.
EEPROM 4K bit (non-volatile memory
(number of writes: 100,000).
2 line x 4 character 7-segment LED display.
Process value (PV): Red color, Set point (SV): Green color.
Thermocouple: K, J, T, E, N, R, S, B, L, U, TXK.
3-wire Platinum RTD: Pt100, JPt100.
PID, ON/OFF, or Manual.
Relay output: SPDT (SPST: 1/16 DIN). Max.600.
Voltage pulse output: DC 14V, Max. output current 40mA.
Current output: DC 4 ~ 20mA output
(Load resistance: Max. 600Ω).
0.1% of measuring range.
Thermocouple or Platinum RTD: 500 msec/per scan.
MODBUS ASCII communication protocol
10 to 55 Hz, 10 m/s
2
for 10 min, each in X, Y and Z direction.
Max. 300 m/s2, 3 times in each 3 axes, 6 directions
32°F to 122°F (0°C to + 50°C)
-4°F to 150°F (-20°C + 65°C)
2000 m or less
0% to 80% (non-condensing)
