ACECO FC1003 - Input Sensitivity; RF Signal Strength Bargraph; Frequency Display Resolution

Input Sensitivity ( Typical )
Amplifier 50 Ohm
Impedance 50 Ohm VSWR less than 2:1
Range 1 MHz - 3 GHz
Sensitivity < 0.8 mV at 100 MHz
< 6 mV at 300 MHz
< 7 mV at 1.0 GHz
< 100 mV at 2.4 GHz
Max. input 15 dBm
RF Signal Strength Bargraph
Frequency 1st Segment Full Scale
27 MHz 7 mV 100 mV
150 MHz 5 mV 90 mV
800 MHz 10 mV 200 mV
Frequency Display Resolution
Range Gate Time (Seconds) LSD Sample Display
0.0625 10 Hz 300.00000 MHz
0.25 1 Hz 300.000000 MHz
1.0 1 Hz 300.000000 MHz
300 MHz
4.0 0.1 Hz 300.0000000 MHz
0.0625 1000 Hz 3000.000 MHz
0.25 100 Hz 3000.0000 MHz
1.0 10 Hz 3000.00000 MHz
3 GHz
4.0 10 Hz 3000.00000 MHz
