Diagram
10
8
2
4
3
11
5
7
6
Front Side Back
1. Work platform
2. Ventilation holes
3. Door lock
4. Handle
5. Power cable wrap
brackets
6. 5" directional lock
caster*
7. 5" locking caster
*Keep the cart rolling in
the fixed direction
8. Power inlet
9. Earthing screw
10. Ventilation holes
11. Door lock
12. Security hook
