Acer Altos R720 Series - System Boards

17
System boards
Mainboard
The mainboard becomes accessible once you open the system. It should
look like the figure shown below.
Item Description Item Description
A Rolling BIOS jumper AA USB connector
B Intel ESB2-E I/O Controller BB Control panel board
connector
