Acer Altos R720 Series - SAS Mid-plane Board

21
SAS mid-plane board
Item Description Item Description
A Fan 1 power connector G Integrated SAS hardware
RAID BBU (battery backup
unit) connector
B Fan 2 power connector H Mid-plane power connector
C Fan 3 power connector I Fan 6 power connector
D Fan 4 power connector J Fan 5 power connector
E Integrated SAS hardware
RAID activation key
connector
K Thumbscrew
F Bridge board connector
