SPECIFICATION
LCD Panel
Driving system TFT Color LCD
Size 23.8"W (60cm)
Pixel pitch 0.275mm(H) x 0.275mm(V)
Brightness 250cd/m
2
(Typical)
Contrast 100,000,000:1Max. (ACM)
Viewable angle 178° (H) 178° (V) (CR≥10)(Typical)
Response time 5ms (GTG,Typical)
Panel Type In-Plane Switching
Video Digital Interface
H-Frequency 30KHz~80KHz
V-Frequency 55Hz~75Hz
Display Colors 16.7M Colors
Dot Clock 170MHz
Max. Resolution 1920 x 1080@60Hz
Plug & Play VESA DDCCI/DDC2B
Energy Efciency Class A
*Annual Energy Consumption 31(kWh) (for HDMI-input Model)
Power consumption
@200cd/m
2
ON Mode 16.91W(typ.)
Sleep Mode 0.34W(typ.)
Off Mode 0.25W(typ.)
Input Connector
VGA (Only VGA Model)
HDMI (Only HDMI Model)
DVI (Only DVI Model)
Input Video Signal
VGA signal (Only VGA Model)
HDMI signal (Only HDMI Model)
DVI signal (Only DVI Model)
Speakers 2W x 2(Only Audio-Input Model)(Typical)
Maximum Screen Size
Horizontal:527mm
Vertical:296mm
Power Source 100-240V~, 50/60Hz
Environmental
Considerations
Operating Temp: 5° to 35°C
Storage Temp: -20° to 60°C
Operating Humidity: 10% to 85%
Dimensions 541.0(W) x 424.4(H) x 212.9 (D)mm
Weight (N. W.) 3.95kg Unit (net)
Mechanism spec
Tilt: -5° to +20°
Detachable foot stand: Yes (by Release button)
External
Controls
Switch / Buttons
Power Button
Left(<) /Right(>)
MENU/ENTER
Auto/Exit
E(Empowering) Key
Functions
Acer eColor Management
Blue Light
Brightness
Contrast
Colour Temp
6-axis Hue
6-axis Saturate
Focus
Clock
H. Position
V. Position
Language
OSD Timeout
Wide Mode
DDC/CI
ACM
Input
OD
Auto Source
Quick start Mode
Reset
* All specications are subject to change without notice.
FindmanualsandotherdocumentsforyourAcerproductontheofcialAcersupportwebsite.
*Annual energy consumption is calculated using the typical power consumption 4 hours per day, 365 days per
year.
