3E A Button:
MENU
To select the programming functions
DOWN
To go backward in the selected functions
UP
To go forward in the selected functions
ENTER
To confirm the selected functions
A
4E A DMX output: For DMX512 link, use 3-pin XLR plug cable to link the next unit.
A
5E ADMX input: For DMX512 link, use 3/5-pin XLR plug cable to input DMX signal
A
6E A Mains output: Connect to supply power for the unit.
3.2 Main Function
To select any functions, press MENU button until the required one is shown on the display.
Select the function by ENTER button and the display will blink. Use DOWN and UP button to
change the mode. Once the required mode has been selected, press ENTER button to
setup or it will automatically return to the main functions without any change after idling
7seconds. Back to the functions without any change press MENU button. The main
functions are shown below:
5 A
