Clean (vacuum)
blades
of
grinder
and replace,
if
necessary.
12.
Replace
grinder
blades by removing
the
3 slotted
screws
in
each
blade.
| 3.
Before
replacing
the
grinder
top, clean
the threads
on
both
halves
and re-lube
with
a
thin
film
of food grade
lubricant.
14.
Replace
grinder
top by
turning
clockr.r'ise
to
start
threads.
Turn
clockwise
until
blades
contact
face
to lbce,
then
back off
6
conrplete
turns.
15.
Calibrate
grinder(s)
(See
"Grinder
Calibration").
Setting
Grinder
Adjustment
to
,,Zero,,
l.
Remove
top panel.
2.
Remove
hopper(s).
3.
Remove
grinder
top
panel.
4.
Slide
PVC
coupling
seals
off
of
couplings
at
worm
gear.
5-
Disconnect
flex
cablc from
coupling
at grinder
ad-iustment
assembly
using
a
3/32
Allen
wrench.
6.
Remove
existing
silicone
Rl'V
ll8
from
head
of
5mm
Allen
screw
in
top
of
grinder.
l.
Using
a 5mm
Allen
wrench
inserted
into
top
of grinder.
turn
grinder
shaft
while
turning
worm
gear
adjuster
clockwise
until
grinder
blades
iust
contact.
8.
Turn
adjuster
7 turns
clockwise.
9.
Adjust
grinder
adjustment
scale
to
,.zero...
10.
Reaftach
flex
cable(s)
to
coupling(s).
I
l.
Slide
PVC
coupling
seals
onto
couplings.
12.
Reset
grinder
adjustment
scale
to
2 5.
l3'
Fill
head
of
5mm
Allen
screw
in
top
ol-grinder
(2
places)
with
silicone
Rl'V
I 18.
14.
Reinstall
top panels.
Grinder
Adjustment
set
to
Zero
