Acrolon TankNET TC-1 User Manual

Power Supply Inlet Connections
36" Max.
Conduit support bracket
Flexible Conduit
Water-tight
Conduit Fitting (½
NPT)
½ NPT Water-tight Hole Plug or
conduit and fittings, depending
on I/O requirements
Power Input Wiring
Cool/Heat Output Wiring
Pump-Ctrl Output Wiring
TC-1 Power Supply
Mounted on ice
shield
Ice Shield on Tank
Temperature Probe Cable
(4-Wire Probe Shown)
TC-1 Power Supply
Water-tight cable gland
(included with TC-1)
UNLESS OTHERWISE SPECIFIED
ALL FITTINGS, CONDUITS, WIRE
AND ALL OTHER INSTALLATION
MATERIALS TO BE PROVIDED BY
OTHER
TC-1 for Power Line Networking Quick Start Installation Guide
Acrolon Technologies, Inc.

Acrolon TankNET TC-1 Specifications

General

Brand	Acrolon
Model	TankNET TC-1
Category	Controller
Language	English
