Engineering & Physical Data A5LCY_(i)
MODEL: A5CKY-ER
MODEL
INDOOR UNIT A5CKY20ER A5CKY25ER
OUTDOOR UNIT A5LCY20CR A5LCY25CR
NOMINAL COOLING CAPACITY
Btu/h 18459 (5220 - 20608) 21564 (2081 - 21564)
W 5410 (1530 - 6040) 6320 (610 - 6320)
NOMINAL HEATING CAPACITY
Btu/h 18868 (5323 - 20574) 22212 (5357 - 24873)
W 5530 (1560 - 6030) 6510 (1570 - 7290)
NOMINAL TOTAL INPUT POWER (COOLING) W 1587 1945
NOMINAL TOTAL INPUT POWER (HEATING) W 1495 1632
NOMINAL RUNNING CURRENT (COOLING) A 7.37 8.89
NOMINAL RUNNING CURRENT (HEATING) A 6.96 7.53
EER W/W 3.41 3.25
COP W/W 3.70 3.99
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR EXV
REFRIGERANT CHARGE kg 1.45 1.50
POWER SOURCE V/Ph/Hz 220~240 /1/ 50
REFRIGERANT TYPE R410A
INDOOR UNIT
CONTROL
AIR DISCHARGE 4 WAY AUTOMATIC LOUVER (UP & DOWN)
OPERATION
WIRELESS OR WIRED MICROCOMPUTER
REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 283 / 600 463 / 980
MEDIUM l/s / CFM 250 / 530 392 / 830
LOW l/s / CFM 203 / 430 340 / 720
SOUND PRESSURE LEVEL (H/M/L) dBA 34 / 31 / 28 44 / 41 / 38
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 265 X 820 X 820
WITH PANEL HEIGHT X WIDTH X DEPTH mm 340 X 990 X 990
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 335 X 900 X 900
PANEL HEIGHT X WIDTH X DEPTH mm 410 X 1070 X 1070
UNIT WEIGHT (UNIT + PANEL) kg 29 + 6
CONDENSATE DRAIN SIZE mm 19.1
FAN
TYPE TURBO
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE CLASS B
RATED INPUT POWER W 89 103
RATED RUNNING CURRENT A 0.40 0.45
MOTOR OUTPUT W 20 30
POLES 6
COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM (HYDROPHILIC FIN)
FACE AREA m
2
0.39
ROW 2
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING COLOUR GREY
OUTDOOR UNIT
AIR FLOW l/s / CFM 869 / 1842
SOUND PRESSURE LEVEL dBA 51
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 753 X 922 X 392
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 793 X 990 X 415
UNIT WEIGHT kg 49
PIPE CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 6.4 6.4
GAS mm 12.7 15.9
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP34
INSULATION GRADE CLASS F
RATED INPUT POWER W 120
RATED RUNNING CURRENT A 0.52
MOTOR OUTPUT W 66
POLES 6
COMPRESSOR
TYPE ROTARY SWING
OIL TYPE ETHER
OIL AMOUNT cm
3
N/A
RATED INPUT POWER (COOLING) W 1296 1690
RATED INPUT POWER (HEATING) W 1334 1518
RATED RUNNING CURRENT
(COOLING)
A 5.66 7.25
RATED RUNNING CURRENT
(HEATING)
A 5.84 6.52
LOCKED ROTOR AMP. A -
COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM (CORR.)
FACE AREA m
2
0.62
ROW 2
CASING COLOUR LIGHT GREY
DRAWING NUMBER 000452103N20 000452103N25
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 8°C DB / 6°C WB
