90
R410A Models
(Cooling only)
MODEL : A5WM 07G / A5LC 07C
MODEL : A5WM 09G / A5LC 10C
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
2.541 1.631 2.345 1.434 2.152 1.241 1.959 1.048 1.766 0.854 1.535 0.623
16
2.588 1.515 2.402 1.335 2.217 1.157 2.033 0.979 1.849 0.801 1.627 0.588
16
2.588 2.038 2.402 1.858 2.217 1.680 2.033 1.502 1.849 1.325 1.627 1.111
17
2.635 1.922 2.459 1.759 2.283 1.597 2.107 1.434 1.931 1.271 1.720 1.076
18
2.680 1.804 2.513 1.657 2.346 1.511 2.179 1.364 2.012 1.217 1.812 1.041
19
2.722 1.686 2.547 1.558 2.372 1.430 2.197 1.302 2.064 1.168 1.904 1.006
20
2.768 1.563 2.610 1.424 2.451 1.284 2.293 1.145 2.135 1.006 1.944 0.839
18
2.680 2.327 2.513 2.181 2.346 2.034 2.179 1.887 2.012 1.740 1.812 1.564
19
2.722 2.210 2.547 2.082 2.372 1.954 2.197 1.826 2.064 1.691 1.904 1.529
20
2.768 2.086 2.610 1.947 2.451 1.808 2.293 1.668 2.135 1.529 1.944 1.362
21
2.812 1.963 2.652 1.816 2.493 1.668 2.334 1.520 2.175 1.372 1.984 1.195
22
2.855 1.840 2.695 1.684 2.535 1.528 2.376 1.371 2.216 1.215 2.024 1.028
23
2.898 1.717 2.738 1.553 2.577 1.388 2.417 1.223 2.257 1.058 2.064 0.860
24
2.941 1.594 2.780 1.421 2.619 1.248 2.458 1.074 2.297 0.901 2.104 0.693
20
2.768 2.348 2.610 2.209 2.451 2.069 2.293 1.930 2.135 1.791 1.944 1.624
21
2.812 2.225 2.652 2.077 2.493 1.929 2.334 1.782 2.175 1.634 1.984 1.456
22
2.855 2.102 2.695 1.946 2.535 1.789 2.376 1.633 2.216 1.477 2.024 1.289
23
2.898 1.979 2.738 1.814 2.577 1.649 2.417 1.485 2.257 1.320 2.064 1.122
24
2.941 1.856 2.780 1.683 2.619 1.509 2.458 1.336 2.297 1.163 2.104 0.955
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
2.720 1.771 2.556 1.606 2.406 1.457 2.257 1.307 2.108 1.158 1.929 0.978
16
2.816 1.656 2.654 1.511 2.499 1.374 2.344 1.236 2.189 1.099 2.003 0.934
16
2.816 2.202 2.654 2.057 2.499 1.920 2.344 1.782 2.189 1.645 2.003 1.480
17
2.912 2.087 2.752 1.962 2.591 1.837 2.431 1.711 2.270 1.586 2.078 1.436
18
3.001 1.964 2.837 1.854 2.674 1.744 2.511 1.634 2.348 1.524 2.152 1.392
19
3.092 1.835 2.940 1.706 2.789 1.577 2.637 1.449 2.451 1.403 2.227 1.348
20
3.177 1.713 3.003 1.603 2.829 1.492 2.656 1.381 2.482 1.271 2.274 1.138
18
3.001 2.510 2.837 2.400 2.674 2.290 2.511 2.180 2.348 2.070 2.152 1.938
19
3.092 2.381 2.940 2.252 2.789 2.123 2.637 1.995 2.451 1.949 2.227 1.894
20
3.177 2.259 3.003 2.148 2.829 2.038 2.656 1.927 2.482 1.817 2.274 1.684
21
3.264 2.130 3.083 2.004 2.901 1.878 2.720 1.751 2.538 1.625 2.320 1.474
22
3.352 2.002 3.162 1.860 2.973 1.718 2.784 1.576 2.594 1.434 2.367 1.263
23
3.439 1.873 3.242 1.715 3.045 1.558 2.848 1.400 2.650 1.242 2.414 1.053
24
3.527 1.744 3.322 1.571 3.117 1.398 2.912 1.224 2.707 1.051 2.461 0.843
20
3.177 2.532 3.003 2.421 2.829 2.311 2.656 2.200 2.482 2.089 2.274 1.957
21
3.264 2.403 3.083 2.277 2.901 2.151 2.720 2.024 2.538 1.898 2.320 1.747
22
3.352 2.275 3.162 2.133 2.973 1.991 2.784 1.849 2.594 1.707 2.367 1.536
23
3.439 2.146 3.242 1.988 3.045 1.831 2.848 1.673 2.650 1.515 2.414 1.326
24
3.527 2.017 3.322 1.844 3.117 1.671 2.912 1.497 2.707 1.324 2.461 1.116
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
