97
HEATING MODE
R410A Models
(Heatpump)
MODEL : A5WM 15GR / A5LC 15CR
COOLING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
3.618 2.383 3.422 2.162 3.193 1.960 2.965 1.757 2.736 1.555 2.461 1.312
16
3.728 2.236 3.525 2.040 3.305 1.853 3.085 1.667 2.865 1.480 2.601 1.256
16
3.728 2.892 3.525 2.697 3.305 2.510 3.085 2.323 2.865 2.137 2.601 1.913
17
3.839 2.745 3.627 2.575 3.416 2.404 3.205 2.233 2.994 2.062 2.740 1.857
18
3.965 2.590 3.756 2.438 3.547 2.287 3.339 2.135 3.130 1.983 2.879 1.801
19
4.093 2.429 3.901 2.268 3.709 2.107 3.517 1.947 3.291 1.855 3.019 1.745
20
4.214 2.271 3.996 2.118 3.778 1.966 3.561 1.813 3.343 1.661 3.082 1.478
18
3.965 3.247 3.756 3.095 3.547 2.943 3.339 2.792 3.130 2.640 2.879 2.458
19
4.093 3.085 3.901 2.925 3.709 2.764 3.517 2.603 3.291 2.512 3.019 2.402
20
4.214 2.928 3.996 2.775 3.778 2.622 3.561 2.470 3.343 2.317 3.082 2.134
21
4.337 2.764 4.108 2.592 3.878 2.419 3.649 2.246 3.420 2.074 3.146 1.867
22
4.460 2.601 4.219 2.408 3.979 2.215 3.738 2.023 3.498 1.830 3.209 1.599
23
4.583 2.437 4.331 2.225 4.079 2.012 3.827 1.799 3.575 1.587 3.272 1.331
24
4.706 2.274 4.442 2.041 4.179 1.809 3.915 1.576 3.652 1.343 3.336 1.064
20
4.214 3.256 3.996 3.103 3.778 2.951 3.561 2.798 3.343 2.646 3.082 2.463
21
4.337 3.092 4.108 2.920 3.878 2.747 3.649 2.575 3.420 2.402 3.146 2.195
22
4.460 2.929 4.219 2.736 3.979 2.544 3.738 2.351 3.498 2.159 3.209 1.927
23
4.583 2.766 4.331 2.553 4.079 2.340 3.827 2.128 3.575 1.915 3.272 1.660
24
4.706 2.602 4.442 2.370 4.179 2.137 3.915 1.904 3.652 1.671 3.336 1.392
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 2.126 2.126 2.406 2.406 2.500 2.500 3.528 3.528 4.088 4.088 4.368 4.368 4.649 4.649
17
2.070 2.070 2.288 2.288 2.440 2.440 3.523 3.523 4.013 4.013 4.290 4.290 4.568 4.568
19 2.015 2.015 2.169 2.169 2.381 2.381 3.519 3.519 3.937 3.937 4.212 4.212 4.486 4.486
21
1.959 1.959 2.102 2.102 2.321 2.321 3.459 3.459 3.862 3.862 4.133 4.133 4.405 4.405
23 1.903 1.903 2.087 2.087 2.262 2.262 3.342 3.342 3.786 3.786 4.055 4.055 4.324 4.324
25
1.847 1.847 2.071 2.071 2.202 2.202 3.225 3.225 3.711 3.711 3.977 3.977 4.243 4.243
27 1.792 1.792 2.055 2.055 2.143 2.143 3.108 3.108 3.635 3.635 3.898 3.898 4.162 4.162
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
FROST REGION
