Exploded View and Part List AWM-G-2009
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
OUTDOOR UNIT
MODEL: ALC 25/28C
No Description Part Number
1 Assy. Base Pan
ALC 25C R50014073884
ALC 28C R50014090627
2 Assy. Outdoor Coil
ALC 25C R50024089206
ALC 28C R50024089206
3 Bracket, Fan Motor R01014070948
4 Fan Motor
ALC 25C R03039028207
ALC 28C R03039024538
5 Fan Propeller R03019023393
6 Assy. Valve Bracket R50014073890
7 Back Panel, Right R01014070950Y
8 Compressor
ALC 25C R04019027570
Assy. Compressor
ALC 28C R50049029625
9 Front Panel, Left R01014070947Y
10 Service Panel R01014070949Y
11 Terminal Cover Panel R01014070838
12 Assy. Control Panel
ALC 25C R50044086076
ALC 28C R50044092855
No Description Part Number
13 Top Panel R01014070596Y
14 Assy. Front Grille R50124093631
15 Plastic Handle R12014057948
16 Assy. Valve Cover R50124073905
17 Assy. Cap Tube
ALC 25C R50024090095
ALC 28C R50024089206
18 Partition R01014070951Y
Parts Not in Diagram
Capacitor, Fan Motor
ALC 25C R04029026759
ALC 28C R04029026966
Capacitor, Compressor
ALC 25C R04029026779
ALC 28C R04029026782
Assy. Flare Valve 3 Ways
5/8”
R50059030462
Assy. Flare Valve 3 Ways
3/8”
R50059030463
Felt, Compressor
ALC 25C R06074084746
ALC 28C R06074079654
