AWM-G-2009 Exploded View and Part List
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
OUTDOOR UNIT
MODEL: A5LC 07C
No Description Part Number
1 Assy. Base Pan R50014057372
2 Assy. Outdoor Coil R50024084360
3 Valve Bracket R01014051164
4 Compressor R04019019592
5 Assy. Partition R50064084355
6 Assy. Cap Tube R50024086530
7 Bracket, Fan Motor R01014052516
8 Fan Motor R03039015324
9 Fan Propeller R03019020744
10 Left Panel R01014052510Y
11 Right Panel R01014084434Y
No Description Part Number
12 Assy. Control Panel R50044086058
13 Top/Front Panel R01014052512Y
14 Assy. Front Grille R50124093629
15 Assy. Valve Cover R50124055172
16 Plastic Handle R12014057948
17 Assy. 2 Ways Valve 1/4” R50059030514
18 Assy. 3 Ways Valve 3/8” R50059030505
Parts Not in Diagram
Capacitor, Fan Motor R04029026755
Capacitor, Compressor R04029026772
OUTDOOR UNIT
MODEL: A5LC 07CR
No Description Part Number
1 Assy. Base Pan R50014057372
2 Assy. Outdoor Coil R50024084312
3 Valve Bracket R01014051164
4 Compressor R04019019592
5 Assy. Partition R50064084355
6 Assy. Cap Tube R50024086526
7 Bracket, Fan Motor R01014052516
8 Fan Motor R03039015324
9 Fan Propeller R03019020744
10 Left Panel R01014052510Y
11 Right Panel R01014084434Y
12 Assy. Control Panel R50044086064
No Description Part Number
13 Top/Front Panel R01014052512Y
14 Assy. Front Grille R50124093629
15 Assy. Valve Cover R50124055172
16 Plastic Handle R12014057948
17 Assy. 2 Ways Valve 1/4” R50059030514
18 Assy. 3 Ways Valve 3/8” R50059030505
Parts Not in Diagram
Capacitor, Fan Motor R04029026755
Capacitor, Compressor R04029026772
Assy. 4 Way Valve R50024086525
Defrost Thermistor R50134039416
