Acson AWM 20G Technical Manual

40
AWM-G-2009 Engineering & Physical Data
General Data - Heat pump (R22)
MODEL
INDOOR UNIT AWM 15GR AWM 20GR
OUTDOOR UNIT ALC 15CR ALC 18CR
NOMINAL COOLING CAPACITY
Btu/h 12000 18000
W 3520 5280
NOMINAL HEATING CAPACITY
Btu/h 12000 18400
W 3520 5390
NOMINAL TOTAL INPUT POWER (COOLING) W 1100 1820
NOMINAL TOTAL INPUT POWER (HEATING) W 980 1660
NOMINAL RUNNING CURRENT (COOLING) A 5.00 8.10
NOMINAL RUNNING CURRENT (HEATING) A 4.50 7.40
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
EER W/W 3.20 2.90
COP W/W 3.59 3.25
REFRIGERANT TYPE R22 R22
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
INDOOR UNIT
CONTROL
AIR DISCHARGE
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
OPERATION LCD REMOTE CONTROL LCD REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 163 / 345 231 / 490
MEDIUM l/s / CFM 135 / 285 193 / 410
LOW l/s / CFM 104 / 220 160 / 340
SOUND PRESSURE LEVEL (H/M/L) dBA 42 / 36 / 29 43 / 40 / 35
UNIT DIMENSION
HEIGHT mm/in 260 / 10.2 304 / 12.0
WIDTH mm/in 799 / 31.5 1062 / 41.8
DEPTH mm/in 198 / 7.8 222 / 8.7
PACKING DIMENSION
HEIGHT mm/in 337 / 13.3 378 / 14.9
WIDTH mm/in 957 / 37.7 1130 / 44.5
DEPTH mm/in 270 / 10.6 292 / 11.5
UNIT WEIGHT kg/lb 12 / 26.5 16 / 35.3
CONDENSATE DRAIN SIZE mm/in 16 / 0.6 20 / 0.8
OUTDOOR UNIT
AIR FLOW l/s / CFM 453 / 960 614 / 1300
SOUND PRESSURE LEVEL dBA 49 51
UNIT DIMENSION
HEIGHT mm/in 540 / 21.3 654 / 25.7
WIDTH mm/in 700 / 27.6 855 / 33.7
DEPTH mm/in 250 / 9.8 328 / 12.9
PACKING DIMENSION
HEIGHT mm/in 620 / 24.4 710 / 28.0
WIDTH mm/in 810 / 31.9 990 / 39.0
DEPTH mm/in 330 / 13.0 415 / 16.3
UNIT WEIGHT kg/lb 32 / 70.5 58 / 127.9
PIPE CONNECTION
TYPE FLARE VALVE FLARE VALVE
SIZE
LIQUID mm/in 6.35 / 1/4 6.35 / 1/4
GAS mm/in 12.7 / 1/2 15.88 / 5/8
REFRIGERANT CHARGE kg/lb 0.80 / 1.76 0.85 / 1.88
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
