Acson AWM 20G Technical Manual

43
Engineering & Physical Data AWM-G-2009
General Data - Cooling Only (R22)
MODEL
INDOOR UNIT A5WM 07G A5WM 09G
OUTDOOR UNIT A5LC 07C A5LC 10C
NOMINAL CAPACITY
Btu/h 7500 9000
W 2200 2640
NOMINAL TOTAL INPUT POWER W 620 860
NOMINAL RUNNING CURRENT A 2.90 3.90
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
EER W/W 3.55 3.07
REFRIGERANT TYPE R410A R410A
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
INDOOR UNIT
CONTROL
AIR DISCHARGE
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
OPERATION LCD REMOTE CONTROL LCD REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 130 / 275 130 / 275
MEDIUM l/s / CFM 106 / 225 106 / 225
LOW l/s / CFM 83 / 175 83 / 175
SOUND PRESSURE LEVEL (H/M/L) dBA 40 / 35 / 29 40 / 35 / 29
UNIT DIMENSION
HEIGHT mm/in 260 / 10.2 260 / 10.2
WIDTH mm/in 799 / 31.5 799 / 31.5
DEPTH mm/in 198 / 7.8 198 / 7.8
PACKING DIMENSION
HEIGHT mm/in 337 / 13.3 337 / 13.3
WIDTH mm/in 857 / 33.7 857 / 33.7
DEPTH mm/in 270 / 10.6 270 / 10.6
UNIT WEIGHT kg/lb 10 / 22.0 10 / 22.0
CONDENSATE DRAIN SIZE mm/in 16 / 0.6 16 / 0.6
OUTDOOR UNIT
AIR FLOW l/s / CFM 307 / 650 396 / 840
SOUND PRESSURE LEVEL dBA 44 46
UNIT DIMENSION
HEIGHT mm/in 495 / 19.5 540 / 21.3
WIDTH mm/in 600 / 23.6 700 / 27.6
DEPTH mm/in 245 / 9.7 250 / 9.8
PACKING DIMENSION
HEIGHT mm/in 575 / 22.6 620 / 24.4
WIDTH mm/in 715 / 28.1 810 / 31.9
DEPTH mm/in 330 / 13.0 330 / 13.0
UNIT WEIGHT kg/lb 26 / 57.3 32 / 70.5
PIPE CONNECTION
TYPE FLARE VALVE FLARE VALVE
SIZE
LIQUID mm/in 6.35 / 1/4 6.35 / 1/4
GAS mm/in 9.52 / 3/8 9.52 / 3/8
REFRIGERANT CHARGE kg/lb 0.60 / 1.32 0.69 / 1.52
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
