AWM-G-2009 Engineering & Physical Data
General Data - Heat pump (R410A)
MODEL
INDOOR UNIT A5WM 10GR A5WM 15GR
OUTDOOR UNIT A5LC 10CR A5LC 15CR
NOMINAL COOLING CAPACITY
Btu/h 9500 12000
W 2780 3520
NOMINAL HEATING CAPACITY
Btu/h 9500 12000
W 2780 3520
NOMINAL TOTAL INPUT POWER (COOLING) W 910 1230
NOMINAL TOTAL INPUT POWER (HEATING) W 770 1080
NOMINAL RUNNING CURRENT (COOLING) A 3.90 5.40
NOMINAL RUNNING CURRENT (HEATING) A 3.40 4.90
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
EER W/W 3.05 2.86
COP W/W 3.61 3.26
REFRIGERANT TYPE R410A R410A
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
INDOOR UNIT
CONTROL
AIR DISCHARGE
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
OPERATION LCD REMOTE CONTROL LCD REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 142 / 300 163 / 345
MEDIUM l/s / CFM 118 / 250 135 / 285
LOW l/s / CFM 94 / 200 104 / 220
SOUND PRESSURE LEVEL (H/M/L) dBA 39 / 34 / 28 42 / 36 / 29
UNIT DIMENSION
HEIGHT mm/in 260 / 10.2 260 / 10.2
WIDTH mm/in 899 / 35.4 899 / 35.4
DEPTH mm/in 198 / 7.8 198 / 7.8
PACKING DIMENSION
HEIGHT mm/in 337 / 13.3 337 / 13.3
WIDTH mm/in 957 / 37.7 957 / 37.7
DEPTH mm/in 270 / 10.6 270 / 10.6
UNIT WEIGHT kg/lb 12 / 26.5 12 / 26.5
CONDENSATE DRAIN SIZE mm/in 16 / 0.6 16 / 0.6
OUTDOOR UNIT
AIR FLOW l/s / CFM 396 / 840 453 / 960
SOUND PRESSURE LEVEL dBA 46 49
UNIT DIMENSION
HEIGHT mm/in 540 / 21.3 540 / 21.3
WIDTH mm/in 700 / 27.6 700 / 27.6
DEPTH mm/in 250 / 9.8 250 / 9.8
PACKING DIMENSION
HEIGHT mm/in 620 / 24.4 620 / 24.4
WIDTH mm/in 810 / 31.9 810 / 31.9
DEPTH mm/in 330 / 13.0 330 / 13.0
UNIT WEIGHT kg/lb 32 / 70.5 32 / 70.5
PIPE CONNECTION
TYPE FLARE VALVE FLARE VALVE
SIZE
LIQUID mm/in 6.35 / 1/4 6.35 / 1/4
GAS mm/in 9.52 / 3/8 12.70 / 1/2
REFRIGERANT CHARGE kg/lb 0.73 / 1.61 0.83 / 1.82
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
