AWM-G-2009 Engineering & Physical Data
Component Data - Cooling Only (R410A)
MODEL
INDOOR UNIT A5WM 10G A5WM 15G
OUTDOOR UNIT A5LC 10C A5LC 15C
INDOOR FAN
TYPE ANTI FUNGUS SKEW FAN ANTI FUNGUS SKEW FAN
QUANTITY 11
MATERIAL ACRYLO NITRILE STYRENE ACRYLO NITRILE STYRENE
DRIVE DIRECT DIRECT
DIAMETER mm/in 97 / 3.8 97 / 3.8
LENGTH mm/in 717.5 / 28.2 717.5 / 28.2
INDOOR FAN MOTOR
TYPE INDUCTION INDUCTION
QUANTITY 11
INDEX OF PROTECTION (IP) IP24 IP24
OUTDOOR FAN
TYPE PROPELLER PROPELLER
QUANTITY 11
MATERIAL
GLASS REINFORCED ACRYL
STYRENE RESIN
GLASS REINFORCED ACRYL
STYRENE RESIN
DRIVE DIRECT DIRECT
DIAMETER mm/in 404 / 16 404 / 16
OUTDOOR FAN
MOTOR
TYPE INDUCTION INDUCTION
QUANTITY 11
INDEX OF PROTECTION (IP) IP24 IP24
COMPRESSOR
TYPE ROTARY HERMETIC ROTARY HERMETIC
OIL TYPE RB68A OR FREOL ALPHA68M RB68A OR FREOL ALPHA68M
OIL AMOUNT cm
3
/ fl .oz. 350 / 12.3 430 / 15.1
INDOOR COIL
TUBE
MATERIAL
SEAMLESS INNER GROOVE
COPPER
SEAMLESS INNER GROOVE
COPPER
DIAMETER mm/in 7.0 / 0.276 7.0 / 0.276
THICKNESS mm/in 0.28 / 0.011 0.28 / 0.011
FIN
MATERIAL
ALUMINIUM (HYDROPHILIC SLIT
FIN TYPE)
ALUMINIUM (HYDROPHILIC SLIT
FIN TYPE)
THICKNESS mm/in 0.11 / 0.0043 0.11 / 0.0043
FACE AREA m
2
/ft
2
0.234 / 2.516 0.234 / 2.516
ROW 22
FIN PER INCH 18 18
OUTDOOR COIL
TUBE
MATERIAL
SEAMLESS INNER GROOVE
COPPER
SEAMLESS INNER GROOVE
COPPER
DIAMETER mm/in 9.52 / 3/8 9.52 / 3/8
THICKNESS mm/in 0.33 / 0.013 0.33 / 0.013
FIN
MATERIAL ALUMINIUM (SLIT FIN) ALUMINIUM (SLIT FIN)
THICKNESS mm/in 0.11 / 0.004 0.11 / 0.004
FACE AREA m
2
/ft
2
0.36 / 3.94 0.36 / 3.94
ROW 11
FIN PER INCH 18 18
AIR QUALITY
FILTER
TYPE NANO FILTER NANO FILTER
QUANTITY pc 22
SIZE
LENGTH mm/in 304 / 11.9 304 / 11.9
WIDTH mm/in 348 / 13.7 348 / 13.7
THICKNESS mm/in 1.5 / 0.06 1.5 / 0.06
NEGATIVE IONIZER YES YES
CASING
INDOOR UNIT
MATERIAL HIGH IMPACT POLYSTYRENE HIGH IMPACT POLYSTYRENE
COLOUR IVORY IVORY
OUTDOOR UNIT
MATERIAL GALVANISED MILD STEEL GALVANISED MILD STEEL
COLOUR LIGHT GREY LIGHT GREY
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
