Acson AWM 20G Technical Manual

75
Performance Data AWM-G-2009
Heat Pump (R22)
Model: AWM 09GR - ALC 09CR
Cooling Mode
ID
DB°C
ID
WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
20
15 3.163 2.063 2.934 1.852 2.705 1.641 2.476 1.430 2.247 1.219 1.972 0.966
16 3.205 1.896 2.978 1.704 2.752 1.513 2.525 1.322 2.299 1.130 2.027 0.901
24
16 3.205 2.420 2.978 2.228 2.752 2.037 2.525 1.846 2.299 1.654 2.027 1.425
17 3.246 2.252 3.022 2.081 2.798 1.909 2.574 1.737 2.351 1.565 2.082 1.359
18 3.287 2.085 3.066 1.933 2.845 1.781 2.624 1.629 2.402 1.476 2.137 1.294
19 .3.29 1.918 3.110 1.785 2.891 1.653 2.673 1.520 2.454 1.388 2.192 1.228
20 3.370 1.750 3.158 1.637 2.947 1.524 2.735 1.410 2.523 1.297 2.268 1.161
28
18 3.287 2.609 3.066 2.457 2.845 2.305 2.624 2.153 2.402 2.001 2.137 1.818
19 3.329 2.442 3.110 2.309 2.891 2.177 2.673 2.044 2.454 1.912 2.192 1.752
20 3.370 2.274 3.158 2.161 2.947 2.048 2.735 1.934 2.523 1.821 2.268 1.685
21 3.413 2.107 3.2140 2.012 3.007 1.918 2.805 1.823 2.602 1.729 2.359 1.615
22 3.455 1.939 3.261 1.864 3.068 1.788 2.875 1.713 2.681 1.637 2.449 1.546
23 3.479 1.772 3.313 1.715 3.129 1.658 2.945 1.602 2.761 1.545 2.540 1.477
24 3.539 1.605 3.364 1.567 3.190 1.529 3.015 1.491 2.840 1.453 2.631 1.408
30
20 3.370 2.536 3.158 2.423 2.947 2.310 2.735 2.196 2.523 2.083 2.268 1.947
21 3.413 2.369 3.210 2.274 3.007 2.180 2.805 2.085 2.602 1.991 2.359 1.877
22 3.455 2.201 3.261 2.126 3.068 2.050 2.875 1.975 2.681 1.899 2.449 1.808
23 3.479 2.034 3.313 1.977 3.129 1.921 2.945 1.864 2.761 1.807 2.540 1.739
24 3.539 1.867 3.364 1.829 3.190 1.791 3.015 1.753 2.840 1.715 2.631 1.670
Model: AWM 09GR - ALC 09CR
Heating Mode
ID
WB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 1.181 1.181 1.471 1.471 1.568 1.568 2.630 2.630 3.210 3.210 3.500 3.500 3.790 3.790
17 1.154 1.154 1.442 1.442 1.538 1.538 2.591 2.591 3.123 3.123 3.402 3.402 3.682 3.682
19 1.126 1.126 1.413 1.413 1.508 1.508 2.552 2.552 3.035 3.035 3.305 3.305 3.574 3.574
21 1.098 1.098 1.383 1.383 1.479 1.479 2.512 2.512 2.948 2.948 3.207 3.207 3.466 3.466
23 1.094 1.094 1.360 1.360 1.449 1.449 2.416 2.416 2.860 2.860 3.110 3.110 3.359 3.359
25 1.090 1.090 1.337 1.337 1.419 1.419 2.320 2.320 2.773 2.773 3.012 3.012 3.251 3.251
27 1.086 1.086 1.314 1.314 1.389 1.389 2.224 2.224 2.686 2.686 2.914 2.914 3.143 3.143
FROST REGION
