109
INDOOR UNIT
MODEL :
A5WM 31
1 / 301R
OUTDOOR UNIT
MODEL :
A5LC 28C / 28CR
Note : Dimension in mm
Note : Dimension in mm
For M5LC / MLC 028 C/CR Only
M
O
D
E
L
ABCDEFG
H
I
J
K
LM
NO
PQ
RS
T
ALC 28C/28CR A5LC
28C/28CR
855
730
328
513
182
44
93
149
101
113
60
3
126
164
17
47
32
3
23
73
75
