AWM-G-2009 Exploded View and Part List
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
OUTDOOR UNIT
MODEL: ALC 25/28CR
No Description Part Number
1 Assy. Base Pan
ALC 25CR R50014073884
ALC 28CR R50014090627
2 Assy. Outdoor Coil
ALC 25CR R50024088731
ALC 28CR R50024088731
3 Bracket, Fan Motor R01014070948
4 Fan Motor
ALC 25CR R03039028207
ALC 28CR R03039024538
5 Fan Propeller R03019023393
6 Assy. Valve Bracket R50014073890
7 Back Panel, Right R01014070950Y
8 Compressor
ALC 25CR R04019027570
Assy. Compressor
ALC 28CR R50049029625
9 Front Panel, Left R01014070947Y
10 Service Panel R01014070949Y
11 Terminal Cover Panel R01014070838
12 Assy. Control Panel
ALC 25CR R50044086136
ALC 28CR R50044092856
No Description Part Number
13 Top Panel R01014070596Y
14 Assy. Front Grille R50124093631
15 Plastic Handle R12014057948
16 Assy. Valve Cover R50124073905
17 Assy. Cap Tube
ALC 25CR R50024088789
ALC 28CR R50024092887
18 Partition R01014070951Y
Parts Not in Diagram
Capacitor,Fan Motor
ALC 25CR R04029026759
ALC 28CR R04029026966
Capacitor, Compressor
ALC 25CR R04029026779
ALC 28CR R04029026782
Assy. Flare Valve 3 Ways
5/8”
R50059030462
Assy. Flare Valve 3 Ways
3/8”
R50059030463
Valve, Rev 4 Way R05019004158
Felt, Compressor
ALC 25CR R06074084746
ALC 28CR R06074079654
