Acson AWM 301 Technical Manual

133
Exploded View and Part List AWM-G-2009
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
INDOOR UNIT
MODEL: AWM/A5WM 20/25G
No
Description Part Number
1 Assy. Chassis R50124068170
2 Fan Motor
AWM/A5WM 20G R03034074205
AWM/A5WM 25G R03034074204
3 Cross Flow Fan R03029029158
4 Fan Bush R11014023775
5 Assy. Indoor Coil
AWM 20G R50024072203
A5WM 20G R50024074031
AWM 25G R50024072204
A5WM 25G R50024072203
6 Piping Clamp R12014071297
7 Assy. Drain Pan R50124068171
8 Assy. Drain Hose R10024015319
9 Assy. Control Box R50044071955
No
Description Part Number
10 Assy. Control Box Cover R50124071418
11 Assy. Front Cover R50124071425
12 Assy. Air Discharge Housing R50124071426
13 Top Louver R12014066820
14 Bottom Louver R12014066821
15 Filter R12014066832
16 Nanosilver Filter R12014080142
Nanovis Filter R12014080144
17 Ionizer R04239022932
18 Handset, Wireless G18 R04084100951
19 Air Swing Motor R03039022933
20 Assy. Mounting Plate R50014036133
21 Control Module R04084071971
Parts Not In Diagram
Rivet (SR-5057) - White R07074049285
INDOOR UNIT
MODEL: AWM/A5WM 20/25GR
No Description Part Number
1 Assy. Chassis R50124068170
2 Fan Motor
AWM/A5WM 20GR R03034074205
AWM/A5WM 25GR R03034074204
3 Cross Flow Fan R03029209158
4 Fan Bush R11014023775
5 Assy. Indoor Coil
AWM 20GR R50024072203
A5WM 20GR R50024074031
AWM 25GR R50024072204
A5WM 25GR R50024072203
6 Piping Clamp R12014071297
7 Assy. Drain Pan R50124068171
8 Assy. Drain Hose R10024015319
9 Assy. Control Box R50044071960
No Description Part Number
10 Assy. Control Box Cover R50124074432
11 Assy. Front Cover R50124071425
12 Assy. Air Discharge Housing R50124071426
13 Top Louver R12014066820
14 Bottom Louver R12014066821
15 Filter R12014066832
16 Nanosilver Filter R12014080142
Nanovis Filter R12014080144
17 Ionizer R04239022932
18 Handset, Wireless G18 R04084100952
19 Air Swing Motor R03039022933
20 Assy. Mounting Plate R50014036133
21 Control Module R04084071973
Parts Not In Diagram
Rivet (SR-5057) - White R07074049285
