Acson AWM 301 Technical Manual

143
Exploded View and Part List AWM-G-2009
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
OUTDOOR UNIT
MODEL: ALC 18/20C
No Description Part Number
1 Assy. Base Pan R50014078281
2 Assy. Outdoor Coil
ALC 18C R50024089940
ALC 20C R50024084570
3 Bracket, Fan Motor R01014070601
4 Fan Motor R03039024539
5 Fan Propeller R03019023393
6 Assy. Valve Bracket R50014072861
7 Back Panel, Right R01014070599
8 Compressor R04019027266
9 Front Panel, Left R01014070597Y
10 Service Panel R01014070598
11 Terminal Cover Panel R01014070838
12 Assy. Control Panel R50044086133
13 Top Panel R01014070596Y
No Description Part Number
14 Assy. Front Grille R50124093631
15 Plastic Handle R12014057948
16 Assy. Valve Cover R50124072885
17 Assy. Cap Tube
ALC 18C R50024089926
ALC 20C R50024087066
18 Partition R01014070603
Parts Not in Diagram
Capacitor, Fan Motor R04029026759
Capacitor, Compressor R04029026782
Assy. Flare Valve 3 Ways
5/8”
R50059030462
Assy. Flare Valve 2 Ways
1/4”
R50059030460
Felt, Compressor R06074084746
OUTDOOR UNIT
MODEL: ALC 18/20CR
No Description Part Number
1 Assy. Base Pan R50014078281
2 Assy. Outdoor Coil
ALC 18CR R50024090296
ALC 20CR R50024075143
3 Bracket, Fan Motor R01014070601
4 Fan Motor R03039024539
5 Fan Propeller R03019023393
6 Assy. Valve Bracket R50014072861
7 Back Panel, Right R01014070599
8 Compressor R04019027266
9 Front Panel, Left R01014070597Y
10 Service Panel R01014070598
11 Terminal Cover Panel R01014070838
12 Assy. Control Panel R50044086143
13 Top Panel R01014070596Y
14 Assy. Front Grille R50124093631
No Description Part Number
15 Plastic Handle R12014057948
16 Assy. Valve Cover R50124072885
17 Assy. Cap Tube
ALC 18CR R50024089931
ALC 20CR R50024087058
18 Partition R01014070603
Parts Not in Diagram
Capacitor, Fan Motor R04029026759
Capacitor, Compressor R04029026782
Assy. Flare Valve 3 Ways
5/8”
R50059030462
Assy. Flare Valve 2 Ways
1/4”
R50059030460
Valve, Rev 4 Way R05019004158
Felt, Compressor R06074084746
