Engineering & Physical Data
Engineering Data - Chilled Water Fan Coil Unit
MODEL ACC06FWD ACC09FWD ACC12FWD ACC15FWD
NOMINAL COOLING CAPACITY
Btu/h 6600 8700 12100 14000
W 1930 2550 3550 4100
NOMINAL SENSIBLE COOLING CAPACITY
Btu/h 5400 6300 9500 9600
W 1580 1850 2780 2810
NOMINAL TOTAL INPUT POWER W 92 108 131 151
NOMINAL RUNNING CURRENT A 0.42 0.50 0.58 0.66
POWER SOURCE V/Ph/Hz 220-240/1/50
INDOOR UNIT
CONTROL
AIR DISCHARGE DUCTED
OPERATION WITHOUT CONTROLLER
AIR FLOW
HIGH CFM 280 310 450 460
MEDIUM CFM 270 300 430 450
LOW CFM 220 280 360 400
EXTERNAL STATIC PRESSURE (H/M/L) Pa 53 / 50 / 34 53 / 50 / 44 55 / 50 / 40 78 / 75 / 60
NOMINAL WATER FLOW RATE
USGPM 0.84 1.06 1.50 1.72
litres/min 3.17 4.00 5.67 6.50
HEAD LOSS (COOLING) kPa 24.9 20.8 17.2 31.2
MAX. WORKING PRESSURE kPa 1608
SURFACE AIR VELOCITY m/s 1.20 1.33 1.25 1.28
SOUND PRESSURE LEVEL (H/M/L) dBA 40 / 39 / 36 40 / 39 / 37 41 / 40 / 37 42 / 41 / 39
UNIT DIMENSION H X W X D mm 247 x 552 x 619 247 x 552 x 870
PACKING DIMENSION H X W X D mm 320 x 630 x 737 320 x 630 x 987
UNIT WEIGHT kg 16 17 23 24
CONDENSATE DRAIN SIZE mm 19.05
PIPE CONNECTION mm 19.05 BSPT FEMALE TREAD ADAPTOR
FAN
TYPE CENTRIFUGAL
DRIVE DIRECT
QUANTITY 1 1 2 2
FAN SPEED
HIGH RPM 1265 1379 1290 1389
MEDIUM RPM 1232 1356 1245 1369
LOW RPM 1107 1290 1115 1290
FAN EFFICIENCY
HIGH % 40.4 37.5 40.0 36.4
MEDIUM % 40.8 39.4 41.1 38.6
LOW % 41.9 42.8 40.1 42.9
FAN MOTOR
TYPE PERMANENT SPLIT CAPACITOR (INDUCTION)
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE B
QUANTITY 1 1 1 1
RATED INPUT
POWER
HIGH W 92 108 131 151
MEDIUM W 86 100 124 131
LOW W 68 84 105 102
RATED RUNNING
CURRENT
HIGH A 0.42 0.50 0.58 0.66
MEDIUM A 0.38 0.44 0.54 0.58
LOW A 0.30 0.37 0.46 0.49
STARTING CURRENT A 0.68 1.08 1.08 1.41
MOTOR OUTPUT W 36 71 71 100
MOTOR EFFICIENCY
HIGH % 37.0 45.9 53.3 53.6
MEDIUM % 35.1 44.0 48.1 52.0
LOW % 28.2 40.0 34.4 46.0
POLES 4 4 4 4
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.11 0.11 0.17 0.17
ROW 3 4 3 4
WATER VOLUME litre 0.38 0.63 0.72 0.96
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 2
CASING COLOUR WITHOUT PAINT
MODE COOLING
ENTERING AIR TEMPERATURE 24°C DB / 18°C WB
ENTERING WATER TEMPERATURE 5.5°C
LEAVING WATER TEMPERATURE 14.5°C
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
