Engineering & Physical Data
Engineering Data - Chilled Water Fan Coil Unit
Low Static Pressure (LSP)
MODEL ACC08GW ACC10GW ACC12GW
NOMINAL COOLING CAPACITY
Btu/h 24000 30000 36000
W 7.03 8.79 10.55
NOMINAL SENSIBLE COOLING CAPACITY
Btu/h 19100 23400 27900
W 5.60 6.86 8.18
NOMINAL TOTAL INPUT POWER W 159 202 241
NOMINAL RUNNING CURRENT A 0.72 0.90 1.05
POWER SOURCE V/Ph/Hz 220-240/1/50
REFRIGERTANT TYPE WATER
INDOOR UNIT
CONTROL
AIR DISCHARGE DUCTED
OPERATION WITHOUT CONTROLLER
AIR FLOW
HIGH CFM 800 1000 1200
MEDIUM CFM 650 805 975
LOW CFM 465 600 810
EXTERNAL STATIC PRESSURE Pa 30/19/10 30/18/11 30/20/13
NOMINAL WATER FLOW RATE
USGPM 5.33 6.66 7.99
litres/min 20.18 25.22 30.26
HEAD LOSS (COOLING) kPa 38 42 38
MAX. WORKING PRESSURE kPa 1608
SURFACE AIR VELOCITY m/s 1.69 2.11 2.05
SOUND PRESSURE LEVEL (H/M/L) dBA 39/34/26 41/37/31 42/39/35
UNIT DIMENSION - (WITH PANEL) H X W X D mm 251x1264x461 251x1264x461 251x1514x461
PACKING DIMENSION - (PANEL) H X W X D mm 595x1437x284 595x1473x284 595x1724x284
UNIT WEIGHT (UNIT + PANEL) kg 26 26 30
CONDENSATE DRAIN SIZE mm 19.05
PIPE CONNECTION mm 19.05 BSPT FEMALE THREAD ADAPTOR
FAN
TYPE BLOWER
DRIVE DIRECT
FAN SPEED
HIGH RPM 1140 1275 1220
MEDIUM RPM 950 1035 1010
LOW RPM 710 805 835
FAN EFFICIENCY
HIGH % 52.90 43.90 37.70
MEDIUM % 53.60 51.20 33.90
LOW % 57.60 57.30 46.70
FAN MOTOR
TYPE PERMANENT SPLIT CAPACITOR (INDUCTION)
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE B
RATED INPUT POWER
HIGH W 159 202 241
MEDIUM W 126 161 187
LOW W 81 115 148
RATED RUNNING
CURRENT
HIGH A 0.72 0.90 1.05
MEDIUM A 0.54 0.70 0.82
LOW A 0.35 0.50 0.65
STARTING CURRENT A 0.93 1.31 1.51
MOTOR OUTPUT W 74 109 122
MOTOR EFFICIENCY
HIGH % 44.00 54.20 51.90
MEDIUM % 32.70 34.80 35.90
LOW % 20.80 21.40 25.20
POLES 4
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.14 0.22 0.22
ROW 3
WATER VOLUME litre 0.62 0.90 1.04
AIR
QUALITY
FILTER
TYPE OPTION (WASHABLE SARANET FILTER OR ALUMINIUM MESH FILTER)
QUANTITY pc 2
CASING COLOUR WITHOUT PAINT
MODE COOLING HEATING
ENTERING AIR TEMPERATURE 27°C DB / 19°C WB 20°C DB
ENTERING WATER TEMPERATURE 7°C
50°C (2 Pipes System)
-
LEAVING WATER TEMPERATURE 12°C -
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
