Outlines & Dimensions
119
Model: ACK10/15/20CW
Dimension
Model
A B C D E F G H I J K
10/15/20
570 570 250 640 408 364 408 640 75 98 364
052075
408
640
408
364
364
SEE DETAIL A
DETAIL A
WATER INLET
WATER OUTLET
A
CB
D
E
F
G
H
K
I
J
Note: Dimension in mm
