Acson AWM Series User Manual

Outlines & Dimensions
132
Model: ADB075/10BW
A
V
Y X W
T
Z
ZC
ZBZD
ZAZ
U
Q
O
L M N M L
S R
ZE
V
YXW
T
Z
ZC
ZB
ZD
ZAZ
U
B HE
I
F
JK
G
C
D
F
G
P
LEFT PIPING (OPTIONAL)
RIGHT PIPING (STANDARD)
NOTE:
FOR HORIZONTAL AIR DISCHARGE
Dimension
Model
A B C D E F G H I J K L M N O P Q
075 1402 1232 1462 1502 53 50 20 117 163 394 48 287 270 288 177 295 65
100 1402 1232 1462 1502 53 50 20 117 163 394 48 287 270 288 177 295 65
Dimension
Model
R S T U V W X Y Z ZA ZB ZC ZD ZE
075 302 103 33 72 761 60 605 96 35 537 437 572 100 132
100 289 103 33 72 761 60 605 96 35 537 437 572 100 145
Note: Dimension in mm
