Nomenclature
4
Remark:
* : Air Flow Rate value under Nomenclature is an indication.
Please refer to Engineering and Physical Data for exact capacity value
Note:
Please consult factory for customised enquiry.
CC 06 F D - 5 C R F A X A AWA
Product Type
CC : Ceiling Concealed
Size*
06 : 600 CFM
09 : 900 CFM
12 : 1200 CFM
15 : 1,500 CFM
Product Series
F : F series
Application
D : District Cooling
(High ∆T ≈ 9°C)
External Static Pressure
5 : 50Pa
8 : 75-80Pa
Coil & Water Pipe Connection
C : 3 Row, Right Piping
D : 3 Row, Left Piping
E : 4 Row, Right Piping
F : 4 Row, Left Piping
Return Air Plenum & Filter
Removal
R : Rear Return & Side/Bottom
Filter Removal
Filter
F : 8mm Saranet Filter
H : 1inch Aluminium Filter
Drain Pan Material & Length
A : Galvanised Steel
E : Stainless Steel & Standard
Length
Motor/Control Module/Wired
Controller
X : AC/Without Control Module/
Without Wired Controller
Revision
A : Revision 1
B : Revision 2
Insulation Material/Thickness
A : PE/Drain Pan
Standard;Return Air Plenum
Without Insulation
K : NBR/Drain Pan
Standard;Return Air Plenum
Without Insulation
Model
W : Chilled Water Fan Coil Unit
Brand
A : Acson
