Acson OM-G12-0104-Acson User Manual

1
1. Transmission source
• The source where the signal will be transmitted.
2. Signal transmission indication
• Blink to confirm that the last setting has been transmitted to the unit.
3. “ON/OFF” Button
• Press once to start the air conditioner unit.
• Press again to stop the unit.
4. Temperature setting
• To set the desired room temperature, press the ▲ or ▼ button to increase or de-
crease the set temperature.
• The temperature setting range is from 16°C to 30°C (Optional setting 20°C to
30°C).
• Press both buttons simultaneously to toggle ▲ and ▼ from °C to °F setting.
5. Operation mode
• Press the MODE button to select the type of operating mode.
• For cooling only unit, the available modes are: COOL ( ), DRY ( ) and FAN ( ).
• For heat pump unit, the available modes are: AUTO ( ), COOL ( ), DRY ( ),
FAN ( ) and HEAT ( ).
6. Fan speed selection
• Press the button continuously will toggle the fan speed in the following order:
Low –––
:
Med –––
:
High –––
:
Auto
• Stop pressing when the desired fan speed appears on the display screen.
7. Turbo function
• Press for fast cooling or heating operation.
• The temperature will be increased internally if it is in HEAT mode, decreased if
in COOL or DRY mode.
Fan speed will be increased if it is not at maximum speed.
• The temperature and fan speed will resume to user setting if is pressed again or
after 20 minutes.
• Available under HEAT, COOL and DRY modes only.
8. ON timer setting
• Press the SET button will activate the on timer function.
• Set the desired on time by pressing the SET button continuously. If the timer is
set to 7.30am, the air conditioner will turn on at 7.30am sharp.
• Press the CLR button to cancel the on timer setting.
OPERATING GUIDE
ENGLISH
OM-G12-0104-Acson 11/21/05, 10:51 AM1
