68
Fan Performance Chart
0
1
2
3
4
5
6
7
300 350 400 450 500 550 600 650 700 750 800
HIGH
MEDIUM
LOW
Pa mmAq
510 600 700 800 900 1000 1100 1200 1300 1360
CFM
CMH
69
59
49
39
29
20
10
0
External Static Pressure
Air Flow
ACC15CW
