2
Table 1.1: Timer ON and Timer OFF key press and event sequence.
TIMER ON KEY TIMER OFF KEY
ON Timer 1 ON Timer 2 OFF Timer 1 OFF Timer 2
Deactivated Deactivated Deactivated Deactivated
Activated Deactivated Activated Deactivated
Deactivated Activated Deactivated Activated
Activated Activated Activated Activated
All timers are event-triggered timers and can be overridden by the ON/OFF button and Override
function.
Set Event 1 and Event 2 Timers
Process for Timer ON and Timer OFF is the same.
Press and hold Timer ON/OFF key for 3 seconds to go into timer setting mode.
(Icon ON 1 or OFF 1 will blink)
Press UP or DOWN to select Timer 1 or Timer 2 to set.
(‘1’ blinking indicate that Timer 1 is currently selected, ‘2’ blinking indicate that Timer 2 is currently
selected)
Press Timer ON/OFF key again to confirm. (Day will blink next)
Press UP or DOWN to select the day.
Press Timer ON/OFF key again to confirm the day. (Hour will blink next)
Press UP or DOWN to change the hour.
Press Timer ON/OFF key again to confirm the hour. (Minute will blink next)
Press UP or DOWN to change the minute.
Press Timer ON/OFF key again to confirm the minute.
Each timer (Timer 1 ON or Timer 1 OFF or Timer 2 ON or Timer 2 OFF) will only be set separately
after all 7 steps, if there is no key operation for 5 seconds during setting the timer, it will automatically
exits from setting mode and no changes will be made.
ON/OFF timer will be checked every 1 minute.
It is not advisable to set ON TIMER and OFF TIMER to have same values. Shall these occur, the
effective timer will be treated with priority as stated in Table 1.2.
Example:
ON TMR 2 settings: DAY – TUE, TIMER – 5.00pm
OFF TMR 1 settings: DAY – TUE, TIMER – 5.00pm
Outcome when RTC reaches 5.00pm on TUE:
when unit is on, no respond.
when unit is off, unit will trigger to on.
Table 1.2: Timer Priority
Priority Timer
1 (Highest) ONTMR2
2 OFFTMR2
3 ONTMR1
4 (Lowest) OFFTMR1
Upon IR reception, IR wireless remote controller will override ON TIMER 2 and OFF TIMER 2
settings.
1.
2.
3.
4.
5.
6.
7.
8.
9.
–
–
