USER MANUAL 750000992/16
6-17
MTS
e
Power meter Specific Functions
9. Press the START/STOP direct access key to execute the automatic result
storage sequence.
The results are printed on the printer at the selected time interval.
10. The sequence is stopped either when the START/STOP key is pressed to stop
the execution or when 300 results have been printed.
Choosing a non calibrated wavelength
If a Light source is transmitting on a specific wavelength the same wavelength
can be selected for the power meter.
To select a specific wavelength:
1. Press the SET-UP direct access key to display the OTS TEST SETUP window.
2. In the power meter configuration menu select User as the Wavelength.
3. Select the require wavelength to match the source with the User Select menu
option.
4. Press the
RESULTS direct access key to display the OTS Results window. The
selected wavelength is displayed on the power meter display.
Setting an audible alarm threshold
In order to easily detect a measurement result that exceeds a chosen threshold
the power meter is equipped with an audible threshold alarm.
To enable the audible alarm:
1. From the OTS Results window press the <Power meter> softkey to access the
power meter functions of the OTS.
2. Press the horizontal arrow keys to get the required alarm level (or, in the
power meter configuration menu, select the alarm threshold level).
3. Press the <Thre. On> to enable the audible threshold alarm.
4. Press the <Thre. Of> to disable the audible threshold alarm.
Note The alarm threshold can also be selected in the Test S et-u p menu.
Transferring OTS table to Excel
See in chapter 8 how to save results in a file and how to transfer OTS table of
results on Excel (see page 8-11).
