Filename
AUTO The file name is automatically created when it is saved,
conforming to the naming conventions given below.
SEMI-AUTO The file name is automatically created when it is saved,
conforming a code defined by the user.
Warning concerning file naming
Note When saving in internal memory (RAM), if the first character of the
identifier is a digit, it will be replaced with an A in the file name.
Note If the identifier is in lower case, the three characters will be con-
verted to upper case.
Note If the identifier contains less than three characters, the missing char-
acters will be replaced with Xs.
OTDR Module Automatic Filenaming
When you store a data to disk using automatic file naming, the filename is
automatically created using the following file naming conventions:
OTDR module automatic file naming: cccffwps
ccc
First three characters of the Cable Id, defined in the
Identifiers section of this menu
ff
0 to 99
A0 to YZ
Fiber number
decimal code
alphanumeric code (100 to 999)
w
Acquisition laser wavelength used for the measurement
31310 nm
51550 nm
61625 nm
8850 nm
9 1300 nm
