9-24
USER MANUAL 750000992/16
Remote control MTS
e
2 to 100: the number of acquisition
0= continuous acquisition
HSEns YES = commutation of High sensitivity saving.
RESO Filter resolution.
FULL: maximum filter resolution (<0,1 nm)
R01, R02, R03, R04, R05
= 0,1 / 0,2 / 0,3 / 0,4 or 0,5 nm.
DETection Detection of channels:
FIRst: on the first acquisition.
GRId: according to the manual grid.
STH Signal presence threshold (-80 to 20 dBm) on the measurement
table. Threshold Auto = - 80.0.
STAtistics YES / NO: to do / not to do statistics.
SNI Space with the peak, from the reference point for the noise:
AUTO
I25ghz, I50ghz, I100ghz: to 25, 50 or 100 GHz of the peak.
SNM Side of the peak from where the reference point is taken for the
noise.
LEFT, RIGHt: left, right.
BOTH: left and right.
NBAnd Width of the noise bandwidth used in the Signal/Noise, from 10
pm to 10 000 pm. Default value 100 pm.
SEScreen Start and end of screen display:
AUTO: Automatic detection of start and end of display.
FULL: Start of display at 1525 nm; End of display at 1570 nm.
MANual: choice of the following commands
MSScreen Choose the start of the display
(from 190.0 THz to 198.0 THz).
MESceen Choose the end of the display (from 190.0 THz to 198.0 THz).
UNIt Unit chosen for the horizontal axis.
GRID Choose the type of reference grid:
ITU FIRst first channel in THz
MAN number of channel
SPA spacing between channel in tenth of GHz
MAN FIRst first channel in THz
MAN number of channel
SPA spacing between channel in tenth of GHz
ASAve Save the locations of the channels to set the automatic
grid on them.
