9-26
USER MANUAL 750000992/16
Remote control MTS
e
Description des fonctions
DATE Acquisition date
TIME Acquisition time
SIZE? Number of points on the curve
*
XOFfset? First point of Abscissa (in THz)
1
XSCale? Space X between two points (in THz)
1
YOFfSet Y axis shift - Coefficient B of «val dB = A*y + B»
1
YSCale? Y axis scale - Coefficient A of «val dB = A*y + B»
1
BUFfer? Reading of the memory containing the curve in ASCII
1
.
FBUffer? Reading of the memory containing the curve in binary.
CURsor A or B cursor position
CURsor? A or B cursor position?
CVAlue? Intersection level (in dBm) point of the A or B cursor and
the curve?
GAIN:TILT? Gain tilt between the cursors in dB?
GAIN:SLOpe? Gain slope in dB /THz?
POWER:TOTal? Power total in dBm?
POWER:COMpos? Composite power?
NCHannel:TOTal? Total number of detected channels at first acquisition?
NCHannel:PREsent? Total number of detected channels at last acquisition?
Commands relative to a channel for which the order number is indicated:
PREsent? Present channel?
AVG? Number of acquisitions on the channel to calculate the
min., max., and average value?
NOIse? Channel noise level?
IBUf? Channel position in the buffer?
FREQ:NOW? Last acquisition channel frequency?
FREQ:AVG Average channel frequency?
FREQ:MIN? Minimum channel frequency?
FREQ:MAX? Maximum channel frequency?
FREQ:SDEV? Channel standard deviation frequency?
*. Refer to the "Reading the buffer storing the trace" on page 9-18.
