9-28
USER MANUAL 750000992/16
Remote control MTS
e
In this example, for the last point, the y value is CB00 in signed hexadecimal.
Thus:
• CB00 in signed decimal = -13568
• the value in dB is:
A*y + B = [-2.939746e-03 x (-13568)] + 34.590000 =- 13533.412 dB
Number of points in the buffer?
OSARESult:SIZE?
Example of response: 32000
Abscissa of the first point in THz?
OSARESul:XOFFset?
Example of response: 196.585464
Interval between 2 points in THz?
OSARESul:XSCale?
Example of response: 7.566895e-04
Coeff B of the function A*y + B?
OSARESult:YOFFset?
Example of response: 34.590000
Coeff A of the function A*y + B?
OSARESult:YSCale?
Example of response: -2.939746e-03
