Acterna MTSe 5000 Series - Technical Specifications (cont.); Application Software and Connectors

11-8
USER MANUAL 750000992/16
Technical specifications MTS
e
5003/2 • for United Kingdom
5003/3 • for USA
5004 Soft carrying case for MTS 5100
e
5005 Hard transit case for MTS 5100
e
5006 Cigarette lighter Power Adapter
Additional AC Adapter / Charger for MTS 5200
e
5007/1 • for Europe
5007/2 • for United Kingdom
5007/3 • for USA
5008 Batch of paper rolls for the MTS 5200
e
internal printer
Application software
9551 WinTrace PC processing software
9552 WinWDM PC processing software
9558 WinCable software to generate measurement report under
Windows™
5996/MTS WS-FTP Pro software to backup the OTDR hard disk to a PC
Connectors supplied with the MTS
e
With OTDR singlemode modules and Light source
One connector is supplied per module: either an universal connector (UNI) with
an adapter (FC, SC, etc.) or a fixed connector (FC, SC, etc.).
FC or Universal connector with adaptor
SC or Universal connector with adaptor
ST or Universal connector with adaptor
DIN or Universal connector with adaptor
E2000
EC
FC/APC or universal low reflectance connector with adaptor
SC/APC or universal low reflectance connector with adaptor
DIN/HRL or universal low reflectance connector with adaptor
With OTDR multimode modules
One connector is supplied per module: either an universal connector (UNI) with
an adapter (FC, SC, etc.) or a fixed connector (FC, SC, etc.).
FC or Universal connector with adaptor
SC or Universal connector with adaptor
ST or Universal connector with adaptor
