Acterna MTSe 5000 Series - Page 207

USER MANUAL 750000992/16
11-13
MTS
e
Specifications of the OTDR modules
Ranges
Ranges for MM and 5023ML modules
Ranges for SR modules
Ranges for DR modules
3 ns 20 ns 50 ns 200 ns
500 m (1.6 kft) xxx
1 km (3.25 kft) xxxx
2 km (6.5 kft) xxxx
5 km (16 kft) xxxx
10 km
(33 kft) xxxx
20 km (65 kft) xxxx
40 km
(131 kft) xxx
80 km (262 kft) x
10 ns 30 ns 100 ns 300 ns 1 µs3 µs10 µs
2 km (6.5 kft) xxx
5 km (16 kft) xxxx
10 km (33 kft) xxxxx
20 km (65 kft) xxxxxx
40 km (131kft) xxxxxxx
80 km (459kft) xxxxx
140 km (459 kft) xxxx
260 km (853 kft) x
5 ns 20 ns 100 ns 300 ns 1 µs3 µs10 µs
2 km (6.5 kft) xxx
5 km (16 kft) xxxx
10 km (33 kft) xxxxx
20 km (65 kft) xxxxxx
40 km (131 kft) xxxxxx
80 km (262 kft) xxxxx
140 km (459 kft) xxxx
260 km (853 kft) xxx
