USER MANUAL 750000992/16
4-1
Chapter
4
4MTS
e
Controls
This chapter describes the MTS
e
commands:
❏ Front panel commands: buttons, softkeys, screen, etc …
❏ Rear panel commands: connectors (power, RS 232, Centronics), disk drive,
optical connector.
Note The MTS
e
is a multi-tasking instrument: the user can simultaneously
make an acquisition, modify the configuration parameters, print the
results and access an internal memory directory or floppy disk direc-
tory.
Front panel
The MTS
e
front panel contains the controls, display and the indications necessary
to analyze the measurement:
• the display and, to the right, the associated softkeys.
• the ON/OFF switch and the On and battery charge leds.
• the direct access keys:
HELP to call the on-line help pages,
PRINT for all printing operations,
FILE for all file storage and management,
START/STOP to execution measurements, and the “Run” indicator to show
that a measurement is underway,
RESULTS for all measurement analysis operations
• the
Run led flashing when the laser is on.
• directional arrow keys .
