Controls MTS
e
Directional arrow keys
The directional arrow keys have two principle functions:
Control keys
The six keys on the screen provide the following functions:
START STOP This START STOP key has two functions. With OTDR module:
- The START function starts an acquisition in accordance with
the chosen parameters. When the key is pressed and held a real
time acquisition is made. The red “RUN” indicator flashes during
the measurement. The results of the measurement are displayed
on the screen at the end of the acquisition.
- The STOP function interrupts the acquisition underway.
SET-UP The SET-UP key calls a menu which provides access to the
following configuration options:
- Test Set up to configure the measurement parameters.
- System Set up to configure the system parameters (display, date,
language, printing, etc …).
- Instrument Set up to configure the instrument (choice of the
module or modules to use).
RESULTS The RESULTS key displays the result (OTDR trace or table) and
allows the measurement to be analyzed.
FILE The FILE key calls the file management menu to save, recall or
delete files from the internal storage media (SRAM or hard disk)
or the floppy disk.
PRINT The Print key starts a printout of the screen or the chosen selection
on the printer configured for the instrument.
HELP Calls the Welcome page giving the main possible actions. A
second press on this key calls the electronic manual (see "Help" on
page 3-18)
Laser activity indicator
The red LED Run flashes the laser is transmitting.
• on the result page, they are used to position zoom and
move the cursor.
• on the setup pages, they are used to scroll though the
menus.
