5-6
USER MANUAL 750000992/16
Using an OTDR module MTS
e
- or select a predefi
ned value : press
the <Preset Inde
x>
softkey and select (using the «
<«and «>» arrows keys) one
of the cable. See in the following table the index for each
cable type. Once a cable has been selected, press the
<Confirm Index> softkey to validate it.
Preset index values
Section A_B: Enable the index N calibration, the distance between the
cursors A and B being known. Selecting this known
distance will display the index of the fiber. The limits of the
distance are given by the index (1.30000 to 1.70000).
Scatter Coeff.: Choose the backscattered coefficient K from -99 dB to -50
dB in 0.1 dB steps. Modification of K modifies the
reflectance and ORL measurements. The default values are
given in "Reflectance" on page 1-2.
Acquisition
The MTS
e
provides three distinct methods of making an acquisition:
❏ A real-time mode, when the MTS
e
makes up to 10 acquisitions per second
and displays the resulting trace on the screen along with a connection status
indicator.
❏ A rapid automatic mode that allows you to make an acquisition with an
automatic configuration process using the minimum of key strokes.
Wavelength (nm) 850 1300 1310 1550 1625
Corning 62.5/125 1.50140 1.49660
Corning 50/125 1.48970 1.48560
SpecTran 62.5/
125
1.49600 1.49100
Litespec 1.46600 1.46700 1.46700
SpecTran SM 1.46750 1.46810 1.46810
Lucent Truewave 1.47380 1.47320 1.47320
Fitel (Furukawa) 1.47000 1.47000 1.47000
Corning SMF-LS 1.47100 1.47000 1.47000
Corning SMF-DS 1.47180 1.47110 1.47110
Corning LEAF 1.46890 1.46840 1.46840
Corning SMF-28 1.46750 1.46810 1.46810
ATT SM 1.46600 1.46700 1.46700
