5-18
USER MANUAL 750000992/16
Using an OTDR module MTS
e
Table of results
To return to the display of only one line of the table, press the <Trace> key.
Information given for each type of event detected
• the type of event with its associated event number:
Non-reflective event (e.g. a splice).
Reflective event (e.g. a connection).
Reflective ghost.
Slope of the fiber (when no fault follows the slope).
End of the fiber.
ORL measurement
Global ORL measurement
