This guide contains the basic information you need to quickly setup the
Device.
For full documentation, please refer to the User Manual downloadable from
the website.
Device Overview
3
2
1
4
5
6
7
8
9
10
11
2
3
4
1
Microphone
Camera Lens
IR LEDs
RFID Card Reader
Push Button
LED Indicators
Green: Power and Network status
Red: Ring and Call status
5
Speaker
Ethernet Port
DC 12V Input
Digital Input / Output
Wiegand connection
(available only on R61C-10)
7
8
9
10
11
6
