Actron cp7676 - Multimeter Basic Functions; Multimeter Overview and Components

8
CYL
4
CYL
5
CYL
6
CYL
OFF
2K
200
200
750
20
2
20M
2M
200K
20K
DC
V
AC
V
OHMS
®
CP7676
RPM
X10
750V AC
200V DC
COM V
4
CYL
5
CYL
DWELL
6
CYL
8
CYL
4
Section 1. Multimeter Basic Functions
Digital multimeters or DMMs have many special features and functions. This section defines these
features and functions, and explains how to use these functions to make various measurements.
1
Alligator Clip Adapters
Some multimeter tests and measurements are more easily done
using alligator clips instead of test prods. For these tests, push
the crimp end of the alligator clip onto the test prod. If the crimp
on the alligator clip becomes loose, then remove the alligator clip
from the test prod and re-crimp using a pair of pliers.
8
7
6
5
4
3
2
9
