Acuity Brands Lighting CPHB - Page 5

Page 5 of 5
912-00271-001 Rev A, 04/2021
CPHB DRIVER REPLACEMENT IMPORTANT SAFETY
INSTRUCTIONS
DRIVER SCREW
PLACEMENT
DRIVER SCREW
PLACEMENT
FIGURE 3: INTERNAL VIEW
INITIAL DRIVER
REPLACEMENT DRIVER
9000LM-15000LM
18000LM
24000LM-30000LM
If two drivers were
replaced with one driver,
ensure that all incoming
LED leads connect to the
corresponding leads on
the driver.
