Acuity Brands Sensor Switch WSX Series User Manual

3 of 4Sensor Switch 900 Northrop Road, Wallingford, CT 06492 Phone: 1.800.PASSIVE sensorswitch.com ©2013 Acuity Brands Lighting, Inc. All rights reserved 07/01/13
WSX Family
H
N
GND
LOAD 2
BLU
BLU
H
N
LOAD 1
BLK
BLK
REMOVE METAL LINK
IF CONNECTING TO
NEUTRAL
GND
H
N
LOAD 1
BLK
BLK
N
H
N
LOAD 2
BLU
BLU
COVERAGE PATTERN
• Small motion (e.g., hand movements) detection up to 20 ft (6.10 m), ~625 ft
2
• Large motion (e.g., walking) detection greater than 36 ft (10.97 m), ~2025 ft
2
• Wall-to-Wall coverage
• Passive Dual Technology (Microphonics) provides
overlapping detection of human activity over the
complete PIR coverage area. Advanced filtering is
utilized to prevent non-occupant noises from
keeping the lights on.
36 30 20 10 0 ft 10 20
30 36
12 9 6 3 0 m
3 6 9 12
Small
motion
detection
Small
motion
detection
to ~20 ft
6
3
0 m
20
10
0 ft
Small motion ~40 ft coverage
TOP VIEW
1.2 m
4 ft
Small motion
detection to ~20 ft
Large motion detection to >36 ft
SIDE VIEW
0 18 27 369
ft
0 6 9 123
m
WIRING TO GROUND NO NEUTRAL
GND
H
N
LOAD 1
BLK
BLK
REMOVE METAL LINK
IF CONNECTING TO
NEUTRAL
GND
H
N
LOAD 1
BLK
BLK
N
SINGLE RELAY SINGLE RELAY
DUAL RELAY
This product is pre-congured for wiring without a neutral, however if connection to neutral is required by code, contractors can quickly and easily convert the unit in seconds.
CONVERSION FROM GROUND ONLY NO NEUTRAL TO NEUTRAL WIRING
120/277 VAC WIRING
BLACK* - Line 1 Input
BLACK* - Load 1 Output
*BLACK wires
can be reversed
}
BLUE* - Line 2 Input
BLUE* - Load 2 Output
*BLUE wires
can be reversed
}
DUAL RELAY
REMOVE METAL LINK
IF CONNECTING TO
NEUTRAL
REMOVE METAL LINK
IF CONNECTING TO
NEUTRAL
REMOVE METAL LINK
IF CONNECTING TO
NEUTRAL
Step 1:
Remove Yellow
Label
Step 2:
Loosen Screws and
Remove Metal Link
Step 3:
Connect Neutral to
Silver Screw and
Ground to Green Screw
WIRING TO NEUTRAL
WIRE COLOR KEY
347 VAC WIRING (-347 Option)
Red wires replace Black wires.
Notes:
- Unit will draw power from either line connection.
- Both poles’ line connection must be same phase.
