nLight ECLYPSE Enclosure
912-00023-001
Page 5
Acuity Brands | One Lithonia Way Conyers, GA 30012 Phone: 800.535.2465 www.acuitycontrols.com © 2017 Acuity Brands Lighting, Inc. All rights reserved. 06/21/17
Knockout Knockout (High Voltage)
Knockout Knockout
nLight Port 1
nLight Port 2
USB 1
USB 2
DIN Rail
DIN Clip
nLight Port 3
(Supports
GFX module)
Ethernet Secondary
Ethernet Primary
Modbus
RS-485
nLIGHT ECLYPSE WIRING DIAGRAM
