Acura 2004 NSX - Page 198

＊
＊
No. Amps. Circuits Protected
No. Amps. Circuits Protected
:SpareFuse
1
2
3
4
5
6
7
8
9
10
11
12
13
14
10 A
10 A
20 A
20 A
20 A
20 A
20 A
120 A
60 A
40 A
30 A
20 A
20 A
30 A
Engine Room Fan
HAC Clutch
Passenger’s Power Seat
Reclining
Driver’s Power Seat
Reclining
Passenger’s Power Seat
Slide
Driver’s Power Seat Slide
ACG (S)
ACG
Air Pump
Rear Defroster
Ignition Switch (B)
Throttle Motor
Cigarette Lighter
Ignition Coil
1
2
3
4
5
6
7
8
10 A
15 A
7.5 A
15 A
15 A
7.5 A
7.5 A
10 A
SRS 1
SRS 2, Fuel Pump
Daytime Running Lights
Heater Control, Rear
Defroster Relay, Cooling
Fan Control
Back-up Lights, Turn
Signals, Alternator
Washer
Starter Signal
Radio
: Canadian Model
Taking Care of the Unexpected
Fuse Locations
195
ENGINE COMPARTMENT FUSE BOX INTERIOR FUSE BOX
