Acura 2012 RL User Manual

Remove the electrical connector
from the bulb by pushing on the
tab and pulling the connector
down.
Remove the bulb by turning it one-
quarter turn counterclockwise.
Ifyouarereplacingthebulbon
the driver’s side, remove the
battery cover (see page ).
Remove the left or right side
engine compartment cover from
thesideyouareworkingonby
carefully pulling the cover out (see
page ).
Open the hood. Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Turn on the headlights to test the
new bulb.
Reinstall the engine compartment
side cover.
Reinstall the battery cover.
(Driver’s side)
2.
3.
1.
4.
5.
6.
7.
8.
9.
457
492
Lights
Maintenance
469
BULB
CONNECTOR
11/07/20 19:01:48 31SJA670_474
