3. CONNECTIONS
Despite all the power and flexibility the S Series monitors have to offer,
setting them up is very straightforward. The only choice you have to make
is whether to drive them digitally or with a traditional analog signal. This
selection is made via the rear-panel OLED display and its adjacent
dual-
function push-button/rotary encoder, which allow access to the
S Series DSP settings.
In addition to a standard IEC mains connector, the simple S Series rear
panel features traditional AES XLR analog inputs and AES3 digital Input
and Thru connectors [the latter are for multi-channel arrays where
multiple speakers are being driven using the same signal]. There's also
a USB jack to facilitate internal software upgrades and the use of
computer-based remote setting software, and a blank panel covering an
Options slot that will hold two RJ45 connectors for future expansion options.
NOTE: Always use AES/EBU-compatible, shielded twisted-pair cables
for digital audio connections.
OLED display
Dual-function
push-button/rotary
encoder
XLR analog input
AES 3 In
AES 3 Out
USB jack
Blank panel
covering an
Options slot for
future expansion
IEC mains connector
